Technical Data
| Outline(mm) | 102:48*48 402:48*96 501:96*48 702:72*72 902:96*96 |
| Control type | 0:PID control 1: step control |
| Input type | 1:thermocouple input 2:RTD input |
| Output type | 1: break output |
| Refrigerating type | 0:no refrigerating 1: step refrigerating 2:proportional refrigerating |
| Alam type | 0:no alarm 1:upper limit alarm 2:low limit alarm |
| Input type | 1:K 2:E 3:Pt100 4:Cu50 6:J |
| Output type | 1:relay contact switch output 2:logic level output(used to control SSR) 3:4-20mA |
| Alam mode | Deviation high alarm |
| Deviation low alarm | |
| Deviation high/low alarm | |
| Band alarm | |
| Process high alarm | |
| Process low alarm | |
| Alam output | 1: 1 alarm output 2:2 alarm output |
| Temperature range | 1: 0℃-100℃ 2: 0℃-150℃ 3: 0℃-400℃ |
| 4:0℃-600℃ 5: 0℃-800℃ 6: 0℃-999℃ | |
| Power supply | 90-260VAC or 24VDC |
