Description:
- Digital time switch with weekly program
- Display: LCD
- Text-oriented user guidance in the display
- ON/OFF operation: 44 on & off
- 4 year power reserve (lithium battery)
- ON-OFF switching times
- Permanent ON/OFF switching
- PIN coding
- Automatic summer/winter time changeover
- 2 channels
- There are six national languages (English, German, Italian, Portuguese and Italian), which can choose and change the language.
Technical Data:
| Product Type | AHC810 |
| Operating voltage | 220V AC |
| Width | 2 modules |
| Installation type | Din rail |
| Type of contact | Changeover contact |
| Switching output | Phase-independent |
| Method of connection terminal | Screw terminals |
| Power reserve | 4 years |
| Switching capacity at 250 V AC, cos φ = 1 | 16A |
| Switching capacity at 250 V AC, cos φ = 0,6 | 10A |
| Incandescent/halogen lamp load 230V | 2600W |
| Energy saving lamps | 170W |
| LED lamp < 2 W | 30W |
| LED lamp 2–8 W | 100W |
| LED lamp > 8 W | 120W |
| Fluorescent lamp load (electronic ballast) | 650W |
| Fluorescent lamp load (conventional) not corrected | 1000VA |
| Fluorescent lamp load (conventional) series-corrected | 1000VA |
| Fluorescent lamp load (conventional) parallel-corrected | 730 VA 80uF |
| Time accuracy at 25 °C | typical ± 2 s/day (quartz) |
| Test approval | CE |
| Type of protection | IP 20 |
| Protection class | II according to EN 60 730-1 |
| Housing and insulation material | High-temperature resistant, self-extinguishing thermoplastic |
| Work temperature: | -10 ~ +50 °C (non-icing) |
| Ambient humidity: | 35~85 RH |
