Operating with voltages below 140V AC/DC reduces heating performance by approx.10%
Dynamic heating up
Energy saving
Wide voltage range
Temperature limiting
Clip fixing
Technical Data:
| Heating element | PTC resistor, temperature limiting |
| Heater body | extruded aluminum profile, anodized |
| Mounting | clip for 35mm DIN rail, EN 60715 |
| Fitting position | vertical airflow (air outlet up, connection on bottom) |
| Operating/Storage temperature | -45 to +70 °C (-49 to +158 °F) |
| Operating / Storage humidity | max. 90 % RH (non-condensing) |
| Protection type/Protection class | IP54/ I (earthed) |
| Accessories | screw fixing, Art. No. 09024.0-00 (1 packing unit = 2 pieces) |
| Note | other voltages on request |
| Art. No. | Operating voltage | Heating | Inrush | Length (L) | Weight (approx.) | Connection |
| capacity1 | current max. | |||||
| 04700.0-00 | 120-240V AC/DC2 | 10W | 1.0A | 52mm | 0.1kg | 3 x 0,5mm2 x 300mm cable (silicone) |
| 04701.0-00 | 120-240V AC/DC2 | 20W | 2.5A | 60mm | 0.2kg | 3 x 0,5mm2 x 300mm cable (silicone) |
| 04702.0-00 | 120-240V AC/DC2 | 30W | 3.0A | 70mm | 0.2kg | 3 x 0,5mm2 x 300mm cable (silicone) |
| 04700.9-00 | 110-120 V AC/DC | 10W | 1.0A | 52mm | 0.1kg | 3 x AWG 20 x 300mm cable |
| 04701.9-00 | 110-120 V AC/DC | 20W | 1.5A | 70mm | 0.2kg | 3 x AWG 20 x 300mm cable |
| 04702.9-00 | 110-120 V AC/DC | 30W | 1.5A | 100mm | 0.2kg | 3 x AWG 20 x 300mm cable |
1at 20°C ( 68°F) ambient temperature
2(min. 110V, max 265V) Operating with voltages below 140V AC/DC reduces heating performance by approx. 10%.
