Characteristics
1.Number of poles:1P, 2P,3P,4P
2.Rated Current(A):16,25,40,63,80,100
3.Rated Voltage(V):AC230/240,400/415(4P)
4.Frequency:50/60Hz
5.Protection degree:IP20
|
Model |
Isolation Switch |
||
|
Code |
KP-L7S |
||
|
Standard |
IEC60947-3 |
||
|
Electrical Features |
Rated current |
A |
32,40,50,63,80,100,125 |
|
Poles |
P |
1P,2P,3P,4P |
|
|
Rated voltage |
V |
240/415 |
|
|
Rated short-time withstand current lcw |
|
12le, 1s |
|
|
Insulation voltage |
V |
500 |
|
|
Rated making and breaking capacity |
|
3le, 1.05Ue, cosφ=0.65 |
|
|
Rated short circuit making capacity |
|
20le, t=0.1s |
|
|
Rated frequency |
Hz |
50/60 |
|
|
Pollution degree |
|
2 |
|
|
Utilization category |
|
AC-22A |
|
|
Mechanical Features |
Electrical life |
t |
1500 |
|
Mechanical life |
t |
8500 |
|
|
Protection degree |
|
IP20 |
|
|
Ambient temperature (with daily average≤35℃) |
℃ |
-5℃...+40℃ |
|
|
Storage temperature |
℃ |
-25℃...+70℃ |
|
|
Installation |
Terminal connection type |
|
Cable/Pin-type bus bar |
|
Terminal size top/bottom for cable |
mm2
|
50
|
|
|
Terminal size top/bottom for bus bar |
mm2
|
50
|
|
|
Tightening torque |
N*m |
2.5 |
|
|
Connection |
|
From top and bottom |
|
