Specification
| Contact | Contact form | 2C 3C |
| Rated load | 10A/250V 28VDC(resistance) 7A/250VAC 28VDC | |
| Chargepower | 2500VA,280W | |
| Contact resistance | ≤50mΩ | |
| Material | Siliver Alloy | |
| Electrial life | ≥100000 Time | |
| Mechanical | ≥1000000 Time | |
| Plok up voltage (at 25℃) | ≤80%Un | |
| Drop out voltage(at 25 ℃) | DC:≥15%Un.AC:≥30% Un | |
| Max continuous voltage | 110% | |
| Insulation resistance | ≥100MΩ(500VDC) | |
| Coil normal power | DC(W) | 1.5 |
| AC(VA) | 2.7 | |
| Operate time | ≤30ms | |
| Release time | ≤20ms | |
| Dielectric Strength | Between open contact | 1200VAC/1min (leak the electric current 1MA) |
| Beteween contact circults | 1200VAC/1min (leak the electric current 1MA) | |
| Between contact andcil | 2500VAC/1min (leak the electric current 1MA) | |
| Ambient temperature | -10~+40℃ | |
| Ambient pressure | 35%`85%RH | |
| Atmospheric | 86~106KPa | |
| Shock resistance | 10G (half a wave of pulses od sine:11ms) | |
| Vibration resistance | 10~50HZ 1.5mm Double Amplitude 1.5mm | |
| Layout style | insert type | |
| Weight | 75g | |
